06S Raven Mods... So far..

Well guys, got tired of the 05 tail section.. Love the look of the 06/07 so I took it upon myself to start the swap. But I didnt just want the swap for looks, I still want the functionality of being able to carry a passenger.

So far Ive got the subframe bolted on, and now im just in the process of painting the donor tail plastics. All thats left after that is buying an 06/07 seat.

Well, here's the pics so far..

Before


After








New exhaust



Calon

2006 R6S (Raven) - 06/07 Tail Swapped
R6xxer is offline
Sponsored Links
Advertisement

post #2 of 69 (permalink) Old 04-06-2009, 11:45 PM
Inferno Red on White

jungmoney's Avatar

Join Date: Feb 2009
Location: Midwest
Posts: 272
Bike: '07 R6
Re: 06S Raven Mods... So far..

subscribed.

..........................heavy lies the crown
jungmoney is offline
post #3 of 69 (permalink) Old 04-07-2009, 01:28 AM
I eat my R6

silversurfer6r's Avatar

Join Date: Jan 2008
Posts: 220
Re: 06S Raven Mods... So far..

can you please explain how you modified the subfram? thanks.
silversurfer6r is offline
post #4 of 69 (permalink) Old 04-07-2009, 01:40 AM
kin
Batman wants my bike...

kin's Avatar

Join Date: Mar 2008
Location: Maryland
Posts: 2,797
Bike: 06 R6
Send a message via AIM to kin
Re: 06S Raven Mods... So far..

can't wait to see it finished



Mods: Full MJS Performance System, Agg Racing Smog Block off plates, Graves no-cut frame sliders, T-Rex Racing spools, Greggs flushmounts, CA integrated tail light, DDM Tuning 8000k HID kit, custom fender eliminator, DB Puig black screen, Michelin Pilot Power tires, etc.
kin is offline
post #5 of 69 (permalink) Old 04-07-2009, 02:46 AM Thread Starter
Custom User Title

R6xxer's Avatar

Join Date: Apr 2007
Location: Calgary, Alberta, Canada
Posts: 135
Bike: 2006 R6S
Send a message via MSN to R6xxer
Re: 06S Raven Mods... So far..

Quote:
Originally Posted by silversurfer6r View Post
can you please explain how you modified the subfram? thanks.
I actually bought an 07 subframe from a member on this forum a month or 2 ago, and used that for the starting point.

After doing some measuring and test fitting, I found the mounting points on the 07 subframe would just not work, no matter how you cut or modified the subframe, not to mention the widths from the original subframe and the 07 were totally off.

So after some more measuring and messing around, I decided that I would use the gas tank mount as a guide for measuring the distance needed on each side to splice on part of the original subframe.

In short as you can see in the second "after" picture, I had a shop weld the donor pieces from my old subframe, then had them fishplate the inside for extra strength (since i dont have a TIG at my disposal).

After getting the subframe back from the welding shop I started the non structural cosmetic work. (Third "after" picture).

I took the mounting pieces from the 07 subframe and cut off the mounting holes then jb welded them inline with the existing pieces on the hybrid subframe. I had previously test fit the subframe, and had marked where i wanted to cut the pieces to make the lines flow properly. So after making the cuts, I smeared on the rest of the JB weld and clamped it in place on both sides, then made a piece to make the bottom line flow aswell and did the same as i did to the top.

After the JB set for a day, I ground it all smooth and covered all joints with flowable putty (dupont), then sanded it all smooth and primed and painted.

Thats about as accurate a description as I can give. If you'd like measurments for cutting points ect, just let me know, or better pictures, with explainations.

Calon

2006 R6S (Raven) - 06/07 Tail Swapped
R6xxer is offline
post #6 of 69 (permalink) Old 04-07-2009, 03:34 AM
The guy your mother loves

ToSweet's Avatar

Join Date: Jun 2007
Location: In your fridge.
Posts: 1,930
Bike: 2008 silver R6
Re: 06S Raven Mods... So far..

that is going to look sweet!


Drop a gear and dissapear.
There is no honor among theives.
A tounge weighs virtually nothing, but few can hold it.
ToSweet is offline
post #7 of 69 (permalink) Old 04-07-2009, 10:51 PM
'Officer...IM SO SORRY'

LampLighter's Avatar

Join Date: Feb 2008
Location: Oceanside CA
Posts: 60
Bike: 07 Candy Red
Re: 06S Raven Mods... So far..

Thats the nicest stand iv ever seen
LampLighter is offline
post #8 of 69 (permalink) Old 04-08-2009, 01:26 AM
It's all fubar

R6_monkey's Avatar

Join Date: Mar 2007
Location: England
Posts: 144
Bike: 2006 R6
Re: 06S Raven Mods... So far..

Wow nice job it's going to look great when it's finished.

I like the last picture where you can see the vacuum cleaner after tidying up but I still don't think the wife will allow me to do that in the house

Leeds United .. Marching on Together


R6_monkey is offline
post #9 of 69 (permalink) Old 04-08-2009, 04:39 AM Thread Starter
Custom User Title

R6xxer's Avatar

Join Date: Apr 2007
Location: Calgary, Alberta, Canada
Posts: 135
Bike: 2006 R6S
Send a message via MSN to R6xxer
Re: 06S Raven Mods... So far..

I bought the house, I`m allowed to use my dining room as a garage... If you look hard you can see an actual dining room table behind the bike leaning against the wall. And the vaccum cleaners for show, theres no cleaning up until I get the whole bike back together lol

Calon

2006 R6S (Raven) - 06/07 Tail Swapped
R6xxer is offline
post #10 of 69 (permalink) Old 04-12-2009, 07:27 PM
I <3 ASS

spiritgarage's Avatar

Join Date: Mar 2009
Location: Da Burgh
Posts: 255
Bike: Your Mom
Re: 06S Raven Mods... So far..

ive been searching for a month for some hard info on this swap. everything ive found has been hacked up subframes or hearsay.

congrats on your swap man, i cant wait to do this to my bike!!!!!!
